Application range

Product features

Configuration and parameter

Item		Basic configuration and technical parameters
Model		HDS-L8000D-Y	HDS-L10000D-Y		HDS-L12000D-Y	HDS-L15000D-Y	HDS-L20000D-Y	HDS-L30000D-Y
Processing capacity (kg/ time)		8000	10000		12000	15000	20000	5000-30000
Overall dimensions	Length (mm)	3636 (base size 2060)					3786 (base size 2060)	4505（base size 2760）
	width (mm)	2190（base size 2060）					2490（base size 2060）	2910（base size 2760）
	Height (mm)	8080		8625	9715	10805	10805	12410
Overall weight (kg)		2600		2800	3000	3200	3400	6400
Ventilator	Form	Diagonal flow type						Diagonal flow type
	Diameter (mm)	750						750
	Number of revolutions (rpm)	1450						1450
Heat supply method	Form	Lance type burner/hot air/steam heat exchange
Fuel		Diesel/coal, rice chaff, biamass
Rated voltage (V)		Single phase 220/ three phases 380						three phases 380
Max. power (kW)		9.07						17.97
Performance	Materials loading time (min)	30-35		40-45	45-50	60-65	70-75	60-65
	Materials discharge time (min)	30-35		40-45	45-50	60-65	70-75	60-65
	Moisture elimination rate (%/h)	0.6-1.0
	(min)Single circulation time (min)	30-35		40-45	45-50	60-65	70-75	60-65

accessory products

Hot blast stoveLearn more

The hot blast heater is researched and designed according to the combustion characteristics of biomass, e.g., rice shell, straw and cavings, etc. After combustion, the clean air is generated through heat exchange. Then, the drying is conducted. It has superior performance and can use various renewable energies. Multiple granular or powdered fuels, e.g., rice shell, straw, sawdust and coal, can be fully combusted at semi-floating state. Its hot air efficiency can reach 70% above and it can realize automatic, semi-automatic production operation.

The application of biomass fuel not only protects the environment but also saves costs. Moreover, it is easy to operate and has excellent effect.
